HD409VRH Hign Bay BLE Motion Sensor With Dimmable Function Strong IP Rating

Product Categories
Shenzhen HAISEN Technology Co.,Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

HD409VRH Hign Bay BLE Motion Sensor With Dimmable Function Strong IP Rating

Brand Name : HAISEN

Model Number : HD409VRH

Certification : UL FCC

Place of Origin : China

MOQ : 120pcs/ctn

Price : Negotiable

Payment Terms : D/A, D/P, T/T

Supply Ability : 1-10pcs Samples Within 2-3 Days; Bulk Order Within 28 Days

Delivery Time : Standard Models Within 3 Weeks

Packaging Details : Packed in Individual box, Reinforced With Paper Flat, Then Packed With Outer Carton

Color : White and Black

IP : 65

Function : Dimmable

Control : Bluetooth and Remote

Contact Now

HD409VRH Hign bay Bluetooth Netwaorking Sensor with Dimmable Function strong IP Rating





*HD409VRH Specification.pdf*



Features:



5.8GHz microwave motion sensor with dimmable function.



Supporting different installation and applications, for surface mounting, traditional LED high bay with aluminium reflector, UFO highbay or linear/triproof high bay.



 Max. installation height is 15m/49.21ft.



 Bluetooth networking HAISEN App control.



 Remote control 6. 5 years warranty.





Sensor Parameter:





Detection area


 25%/50%/75%/100%



Hold time


 5s/30s/1min/3min/5min/10min/20min/30min



Daylight threshold


 2Lux/10Lux/30Lux/50Lux/80Lux/120Lux/Disable



Stand-by period


 0s/10s/30s/1min/5min/10min/30min/+∞



Stand-by dimming level


 10%/20%/30%/50%







Other Parameter:





Operating voltage


 120-277VAC,50Hz/60Hz



Switching capacity


 Max,3.0A@120Vac,50/60Hz; Max,2.0A@277Vac,50/60Hz



Mounting height


 Max.15m ( 49.21ft )



IP rating


 IP65





Control method





On/off / 1-10V Dimming



Bluetooth



Mobile App setting



Remote control (HD02R/HD03R/HD05R)





HD409VRH Hign Bay BLE Motion Sensor With Dimmable Function Strong IP Rating
